Graphics, Sound & Video Cards

GPU

• RX 570, 14 nm FinFET
• 4th Graphics Core Next (GCN)

Engine Clock

• Up to 1244 MHz, Boost

Stream Processors

• 2048

Memory Size/Bus

• 8 GB GDDR5/256-bit

Memory Clock

• 6000 MHz effective

Displays

• Maximum 3 Outputs

Interface

• PCI-Express 3.0

Resolution

• DisplayPort: 5120 x 2880 @60 Hz
• HDMI: 4096 x 2160 @60 Hz
• DVI: 2560 x 1600 @60 Hz

Output

• 1x DVI-D
• 1x HDMI
• 1x DisplayPort 1.4

BIOS Support

• UEFI

API

• OpenGL 4.5
• OpenCL 2.0
• DirectX 12
• Shader Model 5.0

Game Index

• 1080p gaming

Sapphire Features

• Intelligent Fan Control III
• Long Life Capacitor
• Fuse protection

AMD Features

• Radeon VR Ready Premium
• Radeon Software
• Radeon FreeSync Technology
• AMD LiquidVR Technology
• 4th Gen GCN Architecture
• Radeon Chill
• Radeon ReLive DirectX 12 Technology
• AMD Eyefinity Technology (Gaming)
• AMD App Acceleration
• AMD CrossFire Technology
• AMD CrossFire (Bridgeless)
• 3rd Gen 14nm Process Technology
• OpenCL 2.0
• OpenGL 4.5
• AMD PowerTune Technology
• TrueAudio Next
• Unified Video Decoder (UVD)
• Video Code Engine (VCE)
• Virtual Super Resolution
• The Vulkan API

Cooling

• Single fan

Form Factor

• 2 Slots, ITX
• Dimension: 170 (L) x 112 (W) x 36 (H) mm

Power Consumption

• <150 W

OS

• Windows 10, Windows 7, 64-bit operating system required

System Requirement

• 500 Watt or greater power supply (recommended)
• 1 x 6-pin Power Connector
• PCI Express 2.0 or higher version based PC is required with one X16 lane graphics slot available on the motherboard for card compatibility

This product is final sale.
